5Pcs GX16-4 4-Pin 16mm Aviation Pug Male and Female Panel Metal Connector

GX16-4 4-Pin Aviation Connector

The GX16-4 4-Pin Aviation Connector is a high-quality metal connector designed for secure and stable electrical connections. It is widely used in industrial equipment, automation systems, robotics, and DIY electronics projects. Its durable metal body ensures longevity, while the precise pin configuration provides reliable performance in various applications.

Product Overview

This connector set includes 5 pairs of male and female connectors, making it a cost-effective solution for multiple installations. The GX16-4 features a 16mm diameter plug with 4 pins, allowing efficient transmission of electrical signals. With a maximum voltage rating of 400V and a maximum current of 5A, it is ideal for medium-to-high voltage applications.

Key Features

• Model: GX16-4
• Material: Metal
• Color: Silver
• Pin Quantity: 4-Pin
• Plug Diameter: 16mm
• Max Voltage: 400V
• Max Current: 5A
• Withstand Voltage: 1200V AC
• Insulator Resistance: >500MΩ
• Contact Resistance: <10mΩ
• Weight: 26g per connector

Benefits of Using GX16-4 Aviation Connectors

1. High Durability

Made from high-quality metal, these connectors are resistant to wear and tear, ensuring a long lifespan. The robust construction makes them suitable for demanding industrial environments where reliability is essential.

2. Secure Connection

The locking mechanism ensures a firm and stable connection between the male and female parts. This prevents accidental disconnections, making the GX16-4 connector a great choice for critical applications.

3. High Voltage and Current Ratings

With a maximum voltage rating of 400V and a current capacity of 5A, this connector is ideal for medium to high-power applications. The withstand voltage of 1200V AC provides extra safety, reducing the risk of electrical breakdowns.

4. Low Contact Resistance

The contact resistance is less than 10mΩ, ensuring minimal power loss and efficient electrical conduction. This feature is crucial for applications that require stable signal transmission.

5. Excellent Insulation

With an insulator resistance greater than 500MΩ, this connector provides excellent insulation, reducing the risk of short circuits and electrical leakage.

6. Easy Installation

Designed for panel mounting, the GX16-4 connectors are easy to install. The threaded coupling allows users to secure the connection effortlessly without requiring special tools.

7. Versatile Applications

• Industrial Automation: Connecting sensors, actuators, and control systems.
• Robotics: Ensuring secure wiring for robotic arms and automated systems.
• DIY Electronics: Providing reliable connections for custom electronics projects.
• Automobile and Aerospace Industries: Used in electrical wiring for vehicles and aircraft.
• Medical Equipment: Connecting medical devices and instrumentation.

Why Choose GX16-4 Connectors?

Reliable and Cost-Effective

This set of 5 male and female connectors provides excellent value for money. The robust construction and reliable performance make them a cost-effective solution for professionals and hobbyists alike.

Compatibility with Various Devices

The standard GX16-4 design ensures compatibility with various electrical and electronic devices. Whether you are working on industrial automation or a home DIY project, these connectors will serve your needs.

Safe and Efficient Performance

The high insulation resistance, low contact resistance, and secure locking mechanism ensure safe and efficient performance, making these connectors ideal for critical applications.

Installation Guide

Step 1: Preparing the Wires

• Strip the insulation from the ends of the wires you want to connect.
• Ensure the wires are clean and free from oxidation.

Step 2: Soldering the Wires

• Identify the 4-pin configuration.
• Solder each wire to the corresponding pin on the male and female connectors.
• Ensure the solder joints are firm and free from short circuits.

Step 3: Securing the Connection

• Align the male and female connectors.
• Insert the male connector into the female panel mount.
• Rotate the locking mechanism to secure the connection.

Step 4: Testing the Connection

• Use a multimeter to check for continuity between connected pins.
• Ensure there is no short circuit or unwanted resistance.
• Apply power and test the functionality of the connected device.

Frequently Asked Questions (FAQs)

1. What is the maximum voltage this connector can handle?

The GX16-4 connector can handle a maximum voltage of 400V and can withstand up to 1200V AC for short durations.

2. Can this connector be used for outdoor applications?

While the metal body provides durability, these connectors are not fully waterproof. If used outdoors, additional waterproofing measures are recommended.

3. Is soldering required for installation?

Yes, soldering is required to attach the wires securely to the connector pins.

4. Can this connector be used for AC and DC applications?

Yes, the GX16-4 is suitable for both AC and DC electrical applications.

5. What is the difference between GX16-4 and other GX connectors?

The GX16-4 has a 4-pin configuration with a 16mm diameter, while other GX connectors may have different pin numbers and sizes.

6. How do I ensure a strong connection?

• Solder the wires properly.
• Use heat shrink tubing for additional insulation.
• Secure the locking mechanism firmly.

7. Can I use this connector for high-current applications?

The maximum current rating is 5A. For higher currents, consider using a different connector with a higher current rating.

8. Does this product come with a warranty?

Warranty details may vary by seller. It is recommended to check with the retailer for specific warranty information.

What’s in the Box?

• 5 Male Connectors
• 5 Female Panel-Mount Connectors
• User Guide (if provided by the seller)

Conclusion

The 5Pcs GX16-4 4-Pin 16mm Aviation Plug Male and Female Panel Metal Connector is an essential component for secure and efficient electrical connections. Order yours today and enjoy a hassle-free electrical connection experience!
